Frame

Play 20 6061 Alloy Stealth evo, hydroformed tubing, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible

Sizes

One size: 260mm

Fork

MDK 20 Kid, Rigid alloy Stealth stanchions, Post Mount disc brake mount

Headset

Onoff ZS44/ZS56, 1-1/8″, 1.5″ head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º

Stem

Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

MDK XC 1.0, 6061 alloy, rise: 25mm, width: 580mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips

Onoff Twin, 1lock-on

Seatpost

MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 250mm

Saddle

SDG Fly Jr

Front brake

Clarks M2 Junior 160mm IS 6 bolts, one piece rotor

Rear brake

Clarks M2 Junior 160mm IS 6 bolts, one piece rotor

Brake lever

Clarks M2 Junior

Rims

MDK-HP1 20 TLR, 25mm internal width, tubeless ready, 32 spokes

Spokes

CN round stainless steel

Front hub

K8QF, 9x100mm, cup & cone ball bearings, IS 6 bolts

Rear hub

Mahle-Ebikemotion X-35, HG freehub

Front tire

Kenda Booster 20×2.4 single compound 30TPI, wire bead

Rear tire

Kenda Booster 20×2.4 single compound 30TPI, wire bead

Crankset

Samox DM 28T steel, 114mm

Rings

28T, steel

Bottom bracket

BSA, 73mm

Chain

Sram PC951 9s, Powerlock

Rear derrailleur

Microshift Advent, M6195S super short cage

Shift levers

Microshift Advent SL M6195R, 9s

Casette

Microshift Advent 11-38T, 9s

Derailleur hanger

Mondraker M077

Weight

12,9 kg

Display

Mahle-Ebikemotion

Motor

Mahle-Ebikemotion X-35

Battery

Mahle-Ebikemotion Internal 250Wh
