Specifications
Model Code C1122GU
Frame SuperSix EVO Carbon, Gen 5, integrated cable routing, 12×142 thru-axle, BSA 68mm
threaded BB, flat mount disc, integrated seat binder, UDH
Fork SuperSix EVO Carbon, Gen 5, integrated crown race, 12x100mm thru-axle, flat mount disc,
internal routing, 1-1/8” to 1-1/4” Delta steerer, 55mm offset (44-54cm), 45mm offset (56-
61cm)
Rims Vision SC45 I23, carbon, 23mm inner width, 45mm depth
Hubs Vision, centerlock, (F) 12x100mm, (R) Vision, 12x142mm
Spokes 2:1 aero bladed direct pull
Tires Schwalbe One TLR, 700x28c, tubeless ready
Crank Shimano 105 7100, 50/34
Bottom Bracket Shimano BB-RS500, BSA 68
Chain Shimano 105, 12-speed
Rear Cogs Shimano 105 R7100, 11-34, 12-speed
Front Derailleur Shimano 105 Di2 R7170
Rear Derailleur Shimano 105 Di2 R7150, 12-speed
Shifters Shimano 105 Di2 R7170, wireless, 2×12-speed
Handlebar Vision Trimax Aero
Grips Cannondale Bar Tape, 3.5mm
Stem Cannondale C1 Conceal, Alloy, 31.8, -6°
Headset Integrated, 1-1/8” – 1-1/4”
Brakes Shimano 105 R7170 hydraulic disc, 160/160mm CL700 rotors
Brake Levers Shimano 105 Di2 R7170 hydraulic disc
Saddle Fizik Vento Antares R7, 140mm
Seatpost Cannondale C1 Aero 40 Carbon V2, 0mm offset (44-54cm), 15mm offset (56-61cm)
Sizes 44,48,50,52,54,56,58,61
Extras Tubeless valves, Shimano EC300 charging connector, Conceal Stem accessory mount
