Frameset

• Frame

  SmartForm C3 Alloy, SAVE, 1-1/8″ headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
• Fork

  SR Suntour XCM-RL, 100mm, lockout, coil, 42mm offset (27.5″) 46mm offset (29″)
• Headset

  Semi-Integrated, 1-1/8″

Drivetrain

• Rear Derailleur

  Shimano Alivio, Shadow SGS
• Front Derailleur

  Shimano Altus, 34.9mm clamp
• Shifters

  Shimano Alivio, 9-speed
• Chain

  KMC X9, 9-speed
• Crank

  Shimano MT210, 36/22
• Rear Cogs

  Shimano HG200, 11-36, 9-speed
• Bottom Bracket

  Sealed cartridge bearing, square taper

Brakes

• Brakes

  Tektro M275 hydraulic disc, 160/160mm rotors
• Brake Levers

  Tektro hydraulic disc

Wheels

• Front Hub

  Shimano HBTX 505
• Rear Hub

  Shimano FH-TX505
• Brake Type

  Disc
• Rims

  WTB SX19, 32h
• Spokes

  Stainless Steel, 14g
• Tire Size

  2.25
• Wheel Size

  29
• Tires

  Schwalbe Rocket Rick, 29×2.25″ (27.5×2.25″ – XS, SM), K-Guard
• Front Tire

  Schwalbe Rocket Rick, 29×2.25″ (27.5×2.25″ – XS, SM), K-Guard
• Rear Tire

  Schwalbe Rocket Rick, 29×2.25″ (27.5×2.25″ – XS, SM), K-Guard

Components

• Handlebar

  Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
• Stem

  6061 Alloy, 31.8, 7°
• Grips

  Cannondale Dual-Density
• Saddle

  Cannondale Stage 3
• Seatpost

  Cannondale 3, 6061 Alloy, 31.6x350mm (XS – SM), 400mm (MD-XL)
