• Platform

  Mavaro
• Model Name

  Mavaro 2 Low StepThru
• Model Code

  C64044U

Frameset

• Frame

  Mavaro, low step-thru, SmartForm C1 Alloy, removable 600Wh downtube battery, tapered headtube, internal cable routing, 135mm QR hub spacing, post mount disc brake, motor protection, integrated RackLock rack and fender – RackTime SnapIt 2.0 and child seat compatible
• Fork

  Cannondale HeadShok, 50mm travel, Quad Cage needle bearing internals, coil spring, twin chamber semi open-bath oil damping, post mount disc, 110x15mm thru-axle
• Headset

  Acros integrated cable routing, 1.8″ sealed bearings with tapered reducers

E-System

• Drive Unit

  Bosch Performance Line CX 250W 2025
• Battery

  Bosch PowerTube, 600Wh
• Charger

  Bosch 4A
• Display

  Bosch Kiox 300 w/ Mini Remote & System Controller

Drivetrain

• Rear Derailleur

  Shimano Nexus Inter-5E, 5-speed internal gear hub
• Shifters

  Shimano Nexus Revoshift, 5-speed twist shifter
• Chain

  Gates CDX high performance carbon drive belt
• Crank

  Gates Bosch E-bike, w/ 46T sprocket
• Rear Cogs

  Gates CDX, 34T

Brakes

• Brakes

  Tektro HD-M530 Gemini, 4-piston hydraulic disc, 203mm TR rotor (Front), 2-piston hydraulic disc, 180mm TR rotor (Rear)
• Brake Levers

  Tektro HD-M530 Gemini hydraulic disc

Wheels

• Rims

  Alloy, double wall, 32 hole, 25mm internal width, disc-specific
• Spokes

  Stainless Steel, 14g
• Tire Size

  2.2
• Wheel Size

  27.5/29
• Hubs

  (F) Shimano TC500, 15x110mm thru-axle / (R) Shimano Nexus Inter-5E, 5-speed internal gear hub
• Tires

  Continental eContact Plus w/ reflective sidewalls 27.5×2.20″ 55-584 (SM, MD), 29×2.20″ 55-622 (LG, XL)

Components

• Handlebar

  Cannondale Urban Ergo Bar, 6061 Alloy, 25mm rise, 35° sweep, 0° rise, 680mm
• Stem

  Cannondale Urban w/ Intellimount, Alloy, 31.8mm clamp, 60mm, +30°, Acros ICR, w/ SP Connect SPC+ Stem Mount & Kiox mount
• Grips

  Ergon GC10
• Saddle

  Selle Royal Essenza
• Seatpost

  Linear Suspension Seatpost, 31.6, 350mm

Connectivity

• Components

  Compatible with Bosch Connect Module (BCM)

Extra

• Extra 1

  RackLock rear rack (27kg, Racktime SnapIt 2.0 & child seat compatible) with integrated extra-large Trelock U-Lock (key-matched with battery lock), Lezyne Foresite E350 front light and SuperNova TL3-Z rear light with integrated reflector, full-coverage fenders
